| Model | MS-2040 |
| Table Type | Vaccum Absorption |
| X,Y,Z Working Area | 2000×4000×600mm |
| 4th Axis Type | A‑axis swing head, swing angle ±120° |
| Spindle Power | 7.5kw HQD Air-cooling spindle |
| Spindle Speed | 24000RPM |
| Control System | Weihong(Optional: Mach 3 / NC studio / DSP) |
| Motors & Drivers | Leadshine hybrid servo motor (Optional: pure servo motor) |
| X,Y,Z Traveling Positioning Accuracy | ±0.01/2000mm |
| X,Y,Z Rail &Transmission | HIWIN 20mm Guide Rail(Optional:25mm/30mm) |
| Max. Rapid Travel Rate | ≥40000mm/min
|
| Max. Working Speed | ≥20000mm/min |
Command Code
| G Code |
| Working Voltage | AC380V/220V |
| Frame Structure | Welding Structure |
| Running Environment | Temperature:0℃-45℃ |
Interface
| USB |
